BARE-Co PTO Safety Slip Clutch
$589.00
SKU B7230
FREIGHT ESTIMATE: Add to cart for shipping costs.
Description
Tractor PTO safety slip clutch to suit Paddock PTO machinery. Protect your new investment as well as your tractor.
Tractor PTO Safety Slip Clutch
NOTE: The clutch has a splined connection. Make sure to check your PTO shaft before ordering.
These clutches are simple to incorporate with your existing PTO shaft.
- Genuine Paddock Part
- Simple to incorporate on your PTO shaft
- Complete assembly
- 1-3/8" 6 Spline Female to 1-3/8" 6 Spline Male
| Specifications | B7230 | B7233 | B7240 | B7258 |
|---|---|---|---|---|
| Diameter | 150 mm (6") | 200 mm (8") | ||
| Number of Springs | 6 Spring | 8 Spring | ||
| Number of Plates | 2 Plate | 4 Plate | 2 Plate | 4 Plate |
| Dimension "A" | 130 mm (5.2") | 145 mm (5.7") | 130 mm (5.2") | 145 mm (5.7") |
| Power Range | 50 - 80hp | 70 - 100hp | 70 - 100hp | 120 - 150hp |
| Connections | 1-3/8" Z6 male x female | 1-3/8" Z6 male x female | ||
Note, it is the users responsibility to ensure their clutch is installed with adequate guarding. No guard is supplied with this clutch part.
When selecting a clutch make sure you consider the requirement of the implement in addition to the rating of your tractor. Select a clutch that will protect the weakest point in the system.
