Gespasa Adblue Flow Meters
FREIGHT ESTIMATE: Add to cart for shipping costs.
When you can't compromise on quality, look to the Gespasa range of adblue flow meters which offer higher accuracy and exceptional European build quality in a long life battery powered, inline flow meter. These units are constructed from compatible materials which perform with Adblue, water and other Urea based solutions.
Adblue and Liquid Fertiliser Inline Flow Meters
Available in a range of sizes suitable for flow rates from 4 to 400 L/min flows
Large, clear, digital LCD display with long battery life operation
Simple BSP threaded connections
Flow Counter / Totaliser
These flow meters are completely sealed making them suitable for installation in the most aggressive and harsh environments. They are ideal for counting the flow of liquid into tanks, trucks and other farming and irrigation requirements.
The range of meters are accurate to 0.8% and can handle pressures to 5 bar making them suitable for most Adblue and farming related applications.
Constructed from a heavy duty plastic material, the meters achieve great performance from a simple, low complexity design, making them extremely reliable. The display can easily be rotated to accommodate variations in the installation and the long life battery is simple to replace when it is time (approx. 5yrs battery life).
These meters have an internal memory which stores the calibration data along with the totalised flow so there is no risk if loosing your valuable information.
|Flow Meter Specification
MGE-40 4-40 L/min
MGE-110 10-110 L/min
MGE-400 20-400 L/min
|Inlet / Outlet
MGE-40 F1" BSP
MGE-110 F1" GAS (BSP) with PA adapters
MGE-400 F2" GAS (BSP) with flanges
Heavy Duty Plastic
||-10 ºC / +50 ºC
Diesel and Lubricants up to SAE-140 density
Long life button type, up to 4yrs life
Low battery level warning
|Dimensions and Weight
Dim.: 103.5x80x170 mm (diameter x width x height)
Weight: 0.877 kg
Dim.: 125x87x210 mm (Ø x width x height)<br>Weight: 1.35 kg
Dim.: 220x142x175 mm (length x width x height)
Weight: 5.35 kg
