Gespasa Adblue Flow Meters

Current Price $369.00
Original Price $489.00
(inc GST)
SKU MGE-40BLUE

Notify me when back in stock

FREIGHT ESTIMATE: Add to cart for shipping costs.



Description

When you can't compromise on quality, look to the Gespasa range of adblue flow meters which offer higher accuracy and exceptional European build quality in a long life battery powered, inline flow meter. These units are constructed from compatible materials which perform with Adblue, water and other Urea based solutions.

Adblue and Liquid Fertiliser Inline Flow Meters

  • Available in a range of sizes suitable for flow rates from 4 to 400 L/min flows
  • Large, clear, digital LCD display with long battery life operation
  • Simple BSP threaded connections
  • Flow Counter / Totaliser

These flow meters are completely sealed making them suitable for installation in the most aggressive and harsh environments. They are ideal for counting the flow of liquid into tanks, trucks and other farming and irrigation requirements.

The range of meters are accurate to 0.8% and can handle pressures to 5 bar making them suitable for most Adblue and farming related applications.

Constructed from a heavy duty plastic material, the meters achieve great performance from a simple, low complexity design, making them extremely reliable. The display can easily be rotated to accommodate variations in the installation and the long life battery is simple to replace when it is time (approx. 5yrs battery life).

These meters have an internal memory which stores the calibration data along with the totalised flow so there is no risk if loosing your valuable information.

Flow Meter Specification Value
Flow

MGE-40  4-40 L/min

MGE-110  10-110 L/min

MGE-400  20-400 L/min

Inlet / Outlet

MGE-40  F1" BSP

MGE-110  F1" GAS (BSP) with PA adapters

MGE-400 F2" GAS (BSP) with flanges

Display 5-digit totalizer
Construction

Heavy Duty Plastic

IP 66

Operating pressure

5 bar

Operating Temperature -10 ºC / +50 ºC
Accuracy +- 0.8%
Compatible Fluids

Diesel and Lubricants up to SAE-140 density

Battery

Long life button type, up to 4yrs life

Low battery level warning

Make  Gespasa
Warranty

12 month

Dimensions and Weight

MGE-40

Dim.: 103.5x80x170 mm (diameter x width x height)
Weight: 0.877 kg

MGE-110

Dim.: 125x87x210 mm (Ø x width x height)<br>Weight: 1.35 kg

MGE-400

Dim.: 220x142x175 mm (length x width x height)
Weight: 5.35 kg
