This sectional style, electric, drain cleaner by Paddock™ is ideal for small to medium size jobs and is easily transported throughout houses and buildings directly to the source of the problem. The heavy duty construction of this unit makes it perfect for commercial and trade users as well as the home handy person fixing their own blockages. Ideal for unblocking pipes up to 150mm in diameter.
Paddock™ Portable Sewer and Drain Cleaner
High quality industrial 570w motor delivers greater torque
Ideal for clearing pipes 20mm to 150mm diameter
Compatible with a range of common shaft sizes; 8mm (5/16"), 16mm (5/8"), 22mm (7/8").
Compatible with Ridgid and Rothenberger shafts and cutting tools.
Supplied with shafts and cutting tools ready to operate out of the box
2 Yr warranty
Portable Sectional Drain Pipe Cleaner
This unit offers a good balance of portability without sacrificing functionality and can be used for clearing blocked pipes ranging from 20mm through to 150mm. The machine weight is under 20kg which makes it manageable for trade's who need to climb stairs and access building drains in hard to reach locations.
A great feature of the portable drain cleaner by Paddock™ is its ability to use sectional shafts of varying diameters. For smaller complex pipe networks, a soft flexible shaft is key and the ability to work with 8mm or 5/16" shafts allows functionality in pipes down to 20mm diameter. At the other extreme are large 75mm-150mm pipes and for these application the machine can be operated with 22mm (7/8") shafts which offer greater strength of operation with a full range of cutting heads. A 16mm (5/8") shaft can also be used with this machine and this size is perfect for everything in-between most commonly 32-100mm.
The unit is supplied with over 13m of 16mm and 22mm shaft as well as 5m of 8mm shaft and a selection of cutting tools. As these units use a sectional shaft design it's simple to lengthen and shorten shafts to suit the job. A full range of spares and accessories is also available to order.
Operating a Sectional Drain Cleaner Safely
Paddock™ provide a detailed operating manual with every machine which explains the safe operating methods of clearing blocked drains.
This unit is suitable for single person operation and the drive is engaged by pressing the lever conveniently located on top of the drive unit. A safety clutch engages the sectional shaft offering a soft spin engagement. The unit is protected by automatically stopping the rotation on release of the engagement lever.
Drain Cleaner Construction and Features
This model is extremely well constructed and retains its portability whilst still delivering a heavy duty, quality construction. The unit is built utilising a combination of weight saving aluminum and poly construction.
Paddock™ only deliver high quality soft shafts in their sectional drain cleaners. Good quality shafts perform better by delivering flexibility without sacrificing mechanical strength. This can only be achieved with a well controlled heat treating process resulting in a shaft that can go deeper and further than lower cost and low quality alternatives.
The drive mechanism used by Paddock is precision machined and the unique design allows for multiple shaft diameters to be run through a single machine. Change between 8mm, 16mm and 22mm shafts with ease depending on your application and requirements.
Sectional Drain Pipe Cleaner Specifications
||20mm - 150mm
||570 watt, 240V, 50Hz
||up to 400 RPM
|| Clutch and Brake in single lever action
Design allows for use of 8mm, 16mm and 22mm cable to be used
1 length of 8mm x 5m soft shaft in tube
6 lengths of 16mm x 2.3m soft shaft in a cage
3 lengths of 22mm x 4.6m soft shaft in a cage
||Compatible with Ridgid and Rothenberger connectors
|Cutting Tools Included
4 x 16mm drill tools
Straight auger, flexible bulb auger, Retrieving auger, 4 blade cutter
4 x 22mm drill tools
Straight auger, funnel auger, 4 blade cutter, Grease cutter
|| 2 Years
||~18 kg machine weight, accessories extra
This item can be shipped Australia wide and is also available for pick up from our Brisbane warehouse. This item has a shipping weight of over 40kg. We advise contacting us for a freight quote to your location. A fork lift may be required at the receiver's location for unloading, if unavailable a tail lift truck may need to be booked or depot delivery.
