Tractor PTO Flail Mower
Freight costs for heavy & bulky items may differ to the online freight calculator. Some items require a drop tail delivery service where a fork lift is not available to unload.
To order, checkout online and a customer service representative will then contact you to discuss the delivery options.
You can also contact us for a freight quote prior to ordering.
For orders outside of Australia contact us for a quote.
Scintex can ship worldwide.
Description
A powerful, tractor PTO driven flail mower that is ideally suited to the tough Australian conditions. Perfect for paddocks, acreages, lawns and rough terrain with shrubs and brush that needs clearing. Designed and manufactured by Paddock Machinery to the highest quality standards. The large cutting width and hydraulic side shift makes this a popular choice for farmers and acreage owners.
Tractor Flail Mower with Hydraulic Side Shift
-
Best suited to tractors 35-85 HP
- Massive 1,750mm cutting width
-
Fitted with hydraulic side shift option as standard
-
Includes PTO safety clutch as standard
-
Heavy duty construction with quality fixtures
- PADDOCK Australian warranty
The most popular model tractor flail mower. It's simple design makes it incredibly robust, suitable for a wide range of tractors with 3 point linkage in either Category I or II. Due to the popularity, these units are available in one configuration only with the hydraulic side shift fitted as standard, offering incredible value for money. If your tractor is not fitted with rear hydraulic capability, the unit can still be used with the hoses disconnected minus the side shift functionality.
This flail mower is fantastic for shredding long grass but can also work well for bush and shrubs up to 50mm in diameter. The rolling blade design of the flail mower differs from a horizontal swing blade slasher and means if a rock or log is impacted, the individual blade can swing back rather then stopping the entire cutting mechanism. The flail design outperforms other cutting designs in longer grasses where mulching and faster decomposition of the cut grass is desired.
These flail mowers will also deliver a clean and well finished cut to your lawns. The cut height can be adjusted between 20mm / 40mm / 60mm, in addition to the 3-point linkage height adjustment options. The unit is fitted with a self leveling roller and rear scraper. Supplied standard are high quality forged and hardened hammer blades which have been chosen for their performance in the rugged Australian conditions.
The construction of the Paddock™ fail mower is exceptional and extremely heavy duty. The design is well proven and over engineered to last. Paddock™ equipment is designed for the Australian conditions. The gearbox fitted to this unit is strong and from one of the largest gearbox manufactures in the world ensuring long lasting performance. PADDOCK offer a 2 Yr warranty on these flail mowers giving users confidence they are buying a quality built product. All parts to service and maintain your flail mower are available locally making it the perfect choice.
| Tractor Implement Model | SPTOFL180H |
|---|---|
| Brand | Paddock Machinery |
| Cutting Width | 1,750mm |
| Overall Width | 2,000mm |
| Cutting Height | Adjustable skids (~20/40/60mm) |
| Hydraulic side shift |
Standard including hoses and quick connection couplings Side shift (from central); Left - 160mm Right - 120mm |
| Recommended Tractor Power |
35-85 HP Note, due to the fitment of the PTO safety clutch higher hp tractors may be used. The unit is suited to Cat I&II tractors. |
| PTO Speed | 540 RPM |
| Flai Drum Speed |
2125 rpm |
| Cutting Tip Speed | 45.5 m/s |
| Construction | Heavy duty powder coated steel |
| Linkage | 3 Point Linkage - Cat I or II (pins supplied) |
| Weight | 523 kg |
| Dimensions | 2,000mm x 1020mm x 890mm (H) |
| Blades | 24 x Forged and Hardened Hammer Blades |
| PTO Shaft | Included 1-3/8" 6 Spline with slip clutch incorporated |
| PTO Safety Clutch | Fitted as standard |
| Warranty | 2 Year Warranty |
Note: Requires addition of gearbox oil prior to operation. To reduce the storage and shipping size the mower will require some minor assembly before use.
SHIPPING INFORMATION:
This item can be shipped Australia wide and is also available for pick up from our Brisbane warehouse. This item has a shipping weight of over 500kg. We advise contacting us for a freight quote to your location as the online estimator may not be accurate. A fork lift will be required at the receiver's location for unloading otherwise a tail lift truck can be booked.
