Trolltek AC Lithium Battery Chargers
Description
The Trolltek™ range of AC power Lithium Battery chargers are ideal for onboard marine installations in harsh salt water environments. Each unit is waterproof, dustproof and shockproof ensuring they withstand the riggers of the marine world.
Installing a onboard charger saves repeated connection of the charge cables to often difficult to access batteries. A well installed onboard charger will making charging simple and fast after a busy day on the water.
Designed for Lithium
Trolltek™ charges are supplied configured for use with the Trolltek™ range of Lithium batteries with charge voltages pre-set to optime levels making them simple and error free for users. Trolltek™ chargers are also compatible with many other leading brands of Lithium batteries (refer to charge specifications below to check for your application).
Multi-stage charging gives batteries a longer life and better performance compared to traditional battery chargers.
Bulk charge stage keeps the charger at a constant current until a set voltage is reached, this typically achieves 80% of the batteries capacity in the shortest possible time.
Absorption charge stage adjusts the charge rate to bring the battery up to 100% capacity and ensuring maximum absorption.
Trolltek™ chargers include smarts and automatic technology so will not overcharge your lithium batteries and are suitable for constant connection to your battery even after full charge has been achieved.
Specifications | TTKCH1/2/3 | TTKCH4/5/6 |
---|---|---|
Output Power | 300W |
600W |
Input |
230-240V AC 50/60 Hz |
230-240V AC 50/60 Hz |
Output (3 models to choose from) 12V 24V 36V |
14.6V DC (20A) 29.2V DC (10A) 43.8V DC (6.8A) |
14.6V DC (40A) |
Soft Start |
Included |
Included |
Over Voltage Protection |
Included | Included |
Over Temperature Protection |
Included | Included |
Short Circuit Protection |
Included | Included |
Efficiency | 92-96% | 92-96% |
Cable Length |
1m |
1m |
Battery Connections |
8mm ring terminals | 10mm ring terminals |
IP Rating |
65 |
65 |
Dimensions | 190x145x40mm | 200x78x33mm |
Weight | 1.1 kg |
2.1 kg |
Warranty | 1 yr | 1 yr |
